| PETROL 340 |
| Type |
Single Cylinder, 4 stroke, |
|
Petrol Engine, OHC |
| Bore / Stroke |
82mm /64mm |
| Displacements |
338cc |
| Compression Ratio |
8.1 |
| Maximum Power |
11 H.P. @4400 RPM |
| Maximum Torque |
23.7NM @ 2800 RPM |
| Oil Filter |
Spin On |
| Oil Quantity |
1.5 Ltr. |
| Air Cleaner |
Dry Type |
| Engine Weight |
30 kg |
| Cooling System |
Forced Air Cooled |
| Fuel Consumption |
22+/-2 km/ltr. |
| DIESEL- 360 |
| Type |
Single Cylinder, 4 stroke, |
|
Diesel Engine |
| Bore / Stroke |
86mm / 68mm |
| Displacements |
395cc |
| Compression Ratio |
18.1 |
| Maximum Power |
7.5 HP. @ 3600 RPM |
| Maximum Torque |
17 Nm @ 2200 RPM |
| Oil Filter |
Spin On |
| Oil Quantity |
1.3 Ltr. |
| Air Cleaner |
Dry Type |
| Engine Weight |
45 kg |
| Cooling System |
Air Cooled |
| Fuel Consumption |
36 + /-2 km/ltr. |
| TRANSMISSION |
| Type |
Constant Mesh, |
|
Mechanical Selective |
| No. of Gears |
4 Forward + 1 Reverse |
| Gear Ratio |
1st 5:1 |
|
2nd 2.93:1 |
|
3rd 1.84:1 |
|
4th 1.12:1 |
|
Reverse 5.94:1 |
|
Primary 1.142:1 |
|
Final 4.125:1 |
| CLUTCH |
| Type |
Multi Plate Wet Type |
| Front Axle |
Bolted Axel on Leading Link |
| Rear Axle |
Fully Floatin Axel Shaft |
| Steering |
Handle Bar |
| Suspension |
Front : Trailing Link with |
|
Hydraulic Shock Absorber |
|
Rear: 2 Nos. Semi Elliptical Leaf |
|
Spring with Hydraulic Shock Absorber |
| BRAKES |
| Type |
Antidive, all Three Wheels-
Hydraulic |
|
Shock Adjusting Brakes with TMC |
| Front |
Drum Brakes |
| Rear |
Drum Brakes |
| Parking Brake |
Mechanical on Real Wheel |
| CHASSIS |
| Long Member |
Rectangular Closed Section |
| Cross Member |
Round Tube |
| TYRES |
| Size |
4.50 x 10 8 PR |
| ELEC. SYSTEM |
| System Voltage |
12 v |
| Battery |
12 v - 52 Ah Multi Plate Lead |
|
Acid Motorized, Single Glade |
| Alternator (Max Output) |
13.5 v 35 A @ 3600 RPM |
| Wiper |
Motorised Single Blade |
| FUEL TANK |
| Capacity |
7 Liters |
