| SPECIFICATION |
| Engine / Transmission |
|
| Type |
4 Stroke, Single Cylinder, Air cooled |
| Displacement |
346cc |
| Bore X Stroke |
70mm x 90mm |
| Max. Power |
18bhp @ 5000rpm |
| Max. Torque |
27Nm @ 2875rpm |
| Max. Speed |
100km/hour |
| Transmission |
5 speed (Left foot gear shift) |
| Ignition |
Digital TCI |
| Carburettor |
Micarb VM 24 |
| Starting |
Electric Start (Optional) |
| Dimensions |
|
| Length |
2120mm |
| Width |
750mm |
| Wheelbase |
1370mm |
| Saddle height |
740 mm |
| Ground Clearance |
140mm |
| Tyres |
|
| Front |
3.25" X 19" |
| Rear |
3.25" X 19" |
| Electricals |
|
| Head Lamp |
12V - 40/45W |
| System |
12V |
| Braking System |
|
| Front |
Drum 7" Dia. Twin lead |
| Optional Disc Brake 280mm |
Drum 6" Dia. Single lead Rear |
| Suspension |
|
| Front |
Telescopic, Hydraulic Damping |
| Rear |
Swing Arm with Adjustable and Gas filled shock
absorbers |
| Colours Available |
Red, Black |
| |
|
