| Technical Specifications |
| Engine |
| Type |
Single cylinder, 4 Stroke Air Cooled |
| Bore x Stroke, mm |
52.4 x 57.8 |
| No of cylinder |
One |
| Displacement |
124.6 CC |
| Compression ratio |
10.6 :1 |
| Maximum Power in kW @ rpm |
6.0 kw @7000 + 500 rpm |
| Max torque in Nm @ rpm |
9+ 0.5 Nm @ 5500+ 500 rpm |
| Clutch Type |
Centrifugal Dry |
| Transmission |
Continous Variable Transmission (CVT) |
| Frame |
Tubuler |
| Shock absorber |
Front - Leading link with hydraulic Damper |
| Rear - Hydraulically Damped |
| Brake Front and Rear |
Internal expanding shoe |
| Brake Drum FR / REAR Size |
130 mm |
| TYRE SIZE |
Front - 3.50 x 10" |
| Rear - 3.50 x 10" |
| Electrical System |
| Ignition System |
Capacitor Discharge Ignition (CDI) |
| Starting System |
Electric and Kick |
| Battery |
12 V 7 Ah |
| Fuel Tank Capacity |
6 Ltrs |
| Dimensions |
| Wheel base |
1290 mm |
| Ovaral Width |
740 mm |
| Overal Length |
1819 mm |
| Overal Height |
1076 mm |
| Min Ground Clearance |
155 mm |
| Weight |
| Kerb Weight |
105 kg |
| Maximum Gross Weight |
233 kg |
| Lights |
| Head lamp |
12 V 35/35 W |
| Tail / Brake Lamp |
12 V 5/21 W |
| Turn signal light Front |
12 V 16 W |
| Turn signal light Rear |
12 V 10 W |
| Hi beam indicator |
12 V 1.7 W |
| Turn signal indication bulb |
12 V 1.7 W |
| COLOURS - Cappuccino Brown, Majestic Maroon, Pearl White, Mystique Grey, Golden Beige, Fiery Black |
| |
|
