| Specifications |
|
| ENGINE & TRANSMISSION |
|
| Type |
4 Stroke, air cooled OHC |
| Displacement |
147.5cc |
| Maximum Power |
9.95kw / (13.5 bhp) @8500 rpm |
| Maximum Torque |
12.3 Nm @ 6000 rpm |
| Bore x Stroke |
57 mm x 57.8 mm |
| Compression Ratio |
9.5:1 |
| Power to weight ratio |
101.16 bhp / ton |
| Starting |
Electric & Kick Start |
| Ignition |
IDI-Dual mode digital ignition |
| Transmission |
5speed constant mesh |
| SUSPENSION |
|
| Front |
Telescopic Forks, 105mm Stroke |
| Rear |
Monotube inverted Gas filled Shox (MIG) |
| BRAKES |
|
| Front |
240mm |
| Rear |
130mm Drum |
| WHEELS AND TYRES |
|
| Rim size (Front) – Alloy |
1.85 x 17” |
| Rim size (Rear) – Alloy |
2.15 x 18 |
| Tyre size (Front) |
90/90 x 17” |
| Tyre size (Rear |
100/80 x 18” |
| ELECTRICALS |
|
| Battery |
12v, 9.0 Ah (ES) / 5.0Ah (KS) |
| Head lamp |
35/35W Halogen HS1, clear Lens with MFR |
| Tail lamp |
5 W |
| Stop lamp |
21 W |
| Turn signal lamp |
10 w |
| DIMENSIONS, WEIGHTS & CAPACITY |
|
| Wheelbase |
1260 mm |
| Kerb weight |
136 kg |
| Fuel tank capacity |
16.0 ltr |
| Reserve capacity |
2.5 ltr |
| |
|
