| Technical
Specifications |
| ENGINE |
| Engine type |
Air-cooled, 4-stroke, SOHC, 2-valve |
| Cylinder arrangement |
Single cylinder |
| Displacement |
106cc |
| Bore & Stroke |
49.0 x 56.0mm |
| Maximum power |
7.6PS (5.59kW) / 7,500rpm |
| Maximum torque |
7.85N.m / 6,000rpm |
| Starting system |
Kick start / Electric start |
| Clutch type |
Multiple wet type |
| Gear box |
4-speed constant mesh |
| CHASSIS |
| Frame type |
Double cradle type-tubular |
| Tire size (Front / Rear) |
3.00-18-4PR, 42P / 3.00-18-6PR, 52P |
| Brake type (Front / Rear) |
Drum / Drum (130mm Dia) |
| Suspension type (Front / Rear) |
Telescopic Hydraulic / Ajustable, Hydraulic |
| Headlight |
12V 35/35W Halogen bulb (HS1) |
| Tail Lamp |
12V 21 / 5W (12P 24 / 5W) |
| Indicator |
12V 10W (12R 10W) |
| DIMENSIONS |
| Overall l x w x h |
2,000mm x 730mm x 1,050mm |
| Seat height |
1,290mm |
| Wheelbase |
173mm |
| Minimum ground clearance |
119kg / 130kg |
| Fuel tank capacity |
13 liters |
